FN 509® Tactical

The FN 509® Tactical, an extension of the FN 509 family, is based on FN’s submission pistol that the U.S. Army tested for its Modular Handgun Trials.

Suggested price: 999 € / £ 900

The FN 509® Tactical, an extension of the FN 509 family, is based on FN’s submission pistol that the U.S. Army tested for its Modular Handgun Trials, but includes the significant improvements to the design that were implemented in the FN 509.

The pistol features the company’s U.S Patent No. 10/352,654 Low-Profi le Optics Mounting System™ that enables the platform to accept more than ten commercially-available miniature red dot (MRD) optics that co-witness with the suppressor-height sights and remain adaptable to future optics releases with no requirement of direct milling of the slide.

The slide cap, for use when not shooting with an optic, has raised sight wings that protect iron sight alignment if the pistol is dropped or jostled, and provides a textured ramp for racking the slide against a belt loop, pant pocket or boot.

An FN-signature 4.5-inch, cold hammer-forged, stainless-steel barrel with target crown, ½” x 28 threads that accept the bulk of 9mm suppressors available and thread cap with integrated O-ring to prevent loosening during use complete the top end.

CALIBER: 9×19 mm
OPERATION: Double-action
MAG CAPACITY: 17 Rd.
WEIGHT: 790gr
BARREL LENGTH: 11,40 cm
OVERALL LENGTH: 20 cm
TWIST RATE: 1:10” RH
HEIGHT: 14,60 cm
WIDTH: 3,40 cm
TRIGGER PULL: 2,5 – 3,5 kg
SIGHT RADIUS: 14,70 cm

PRIMARY FEATURES

Striker-fired autoloader
2,50 to 3,50 kg trigger pull
Threaded Barrel
High-mounted sight with sound moderator and red-dot optics

BARREL

Cold hammer-forged stainless steel
Recessed target crown
Polished chamber and feed ramp
1/2” x 28 threaded Barrel
O-Ring retention thread cap

SLIDE

FN Low Profi le Optics Mounting System™ (U.S Patent No. 10/352,654)
Sight Protecting Slide Cap
External extractor; loaded chamber indicator
Slide with grooved front and rear grip surfaces for ease of handling

MAGAZINE

High visibility, low-friction follower; polymer base with black finish

FRAME

Polymer construction with replaceable steel frame/slide rails
Enhanced grip texture which enables faster folow-up shots in all conditions
Interchangeable backstraps
MIL-STD-1913 accessory mounting rail

OPERATING CONTROLS

Fully ambidextrous slide stop lever and magazine release

SHIPS WITH

Two interchangeable backstraps
Four mounting plate MRD
Two 17-round magazines
Owner’s manual
Locking device
FN logo soft pistol case



FN66-10167093 FN 509T BI NMS FDE/FDE NDS 2×17
FN66-10166993 FN 509T BI NMS BLK/BLK NDS 2×17
